REVIT 3D MODELING

We offer design-oriented Revit modeling services

Whether you need Architectural, structural, or MEP 3d models, our Revit modeling services help our clients with customizing the 3d models as per their design requirements. Depending upon the design development stage of a construction project, we add necessary graphical and non graphical information. The information integrated into the Revit model typically includes the design element details; walls, beams, columns, MEP equipment, material rates, lifecycle information, etc.

We take 2D architectural & engineering designs from you and transform them into interactive Revit models effective for design decision making, cost forecast, facilities, and project management”

Revit modeling process – Augmenting the design process

Step 1) Deciding the discipline for Revit 3D Modeling

If you need Revit modeling services for a specific discipline i.e., structure/architecture then please feel free to share the 2D designs with us. We offer discipline-specific Revit 3D modeling services in all disciplines right from conceptual design development to the detailed design development stage.

Step 2) Reviewing the 2D designs for delivering you the Revit models

We critically review the AutoCAD or pdf drawings for Revit modeling. We get in touch with you if we need any additional information or have any questions. This we do by arranging a one-on-one online meeting with our Revit modeling specialist.

Step 3) Deciding level of development (LOD) for Revit modeling

After choosing the discipline and reviewing the designs we plan the required level of development (LOD) for Revit 3D modeling. The level of development (LOD) is a criterion for choosing the level of information added to the Revit models. This typically includes geometrical, construction timeline, cost, and lifecycle details of a project.

Step 4) Proposal for Revit Modeling Services

We provide you with a quotation and expected turnaround time depending upon your requirements.Please note we offer a 20% discount on the same-day deals and 10% off to our new clients.

Choose the right level of development (LOD) for your project

LOD 200​

A basic model contatining general details. Elements are modelled with estimated amounts, size, shape, placement, and orientation in this general model.

Non-geometric data can also be attached to model elements.

LOD 300

The model is visually represented as a single unit. The parameters such as size, shape, quantity and orientation of the design components are defined in the model.

The non-graphical data is the building metadata. Material, fire resistance class, colour, cost, and manufacturer could all be associated to each component created in BIM software.

LOD 400

This is a fabrication model. The elements of LOD 400 model have precise geometry and parameters of buidling components in addition to the information integrated from LOD 300 model.

The information typically includes fabrication, assembly and detailing of design components.

LOD 500

LOD 500 is also know as As-Built model. This mode is typically used for operations, lifecycle and maintenance.

Non-geometric information such as warranty dates, manufacture details, bills etc. is added to modelled LOD 400 components. The dimensions, form, placement, quantity, and orientation are same as the actual construction.
